Introduction of Fiber Laser Hair Removal Machine for Beauty Salon
Fiber Laser Hair Removal Machine for Beauty Salon uses FCD (Fiber Coupled Diode) technology, meaning the light generated by multiple diode laser are coupled into a single-core multimode fiber by micro lens array, in order to deliver light to the target place.
Fiber-coupled (also called fiber-integrated) diode lasers have several advantages:
The light exiting the fiber has a circular and smooth (homogenized) intensity profile and a symmetric beam quality, which is in many cases very convenient. For example, less sophisticated optics are required for generating a circular pump spot for an end-pumped solid-state laser.
It becomes possible to remove the laser diodes together with their cooling arrangements e.g. from a solid-state laser head, which can then be more compact, and more space is left for other parts at this place.
Defective fiber-coupled diode lasers can easily be replaced without changing the alignment of the device where the light is used.
Fiber-coupled devices can be easily combined with other fiber-optic components.
Working Theory of Fiber Laser Hair Removal Machine
The light generated by multiple diode laser are coupled into a single-core multimode fiber by micro lens array, in order to deliver light to the target place.
Features:Low damage rate, Uniform energy distribution, Long lifespan, Easy maintenance.
Normal diode laser mostly are Vertical Laser Stack with a number of diode bars, which are arranged in a form of stack. The laser chip are welded on heat sinks to deliver high output energy.
Functions of Fiber Laser Hair Removal Machine for Beauty Salon
1.A Gold standard in Permanent hair removing
2.Remove unwanted hair used for any skin type, hair type.
3.Skin rejuvenation
4.Hair removal for the whole body: hairline, lip, whiskers, armpit; body hair and bikini hair removal.
5.Fiber diode laser enables the light to penetrate deeper into skin and is safer than other lasers because it can avoid the melanin pigment in the skin's epidermis. We can use it for permanent hair reduction of all color hairs on all 6 skin types, including tanned skin.
6.Fiber diode laser allows fast repetition rates up to 10Hz(10 pulses-per-second), with in-motion treatment, fast hair removal for big area treatment.
7.Probe built in with excellent contact cooling technology, PAIN-FREE hair removal.
Advantages of Fiber Laser Hair Removal Machine for Beauty Salon
1.A versatile laser hair removal system for 6 skin types. Wavelength 808nm is most effectively absorbed by melanin in the widest range of hair shades and textures.
2.The most comfortable hair remvoal treatment, the powerful cooling system ensure a painless treatment
3.Efficient energy transmission, 3-4times stronger than traditional diode laser
4.Continuous wave, high power
5.Uniform energy distribution
6.Low damage rate
7.Life span up to 50 million shots
Benefits of Fiber Laser Hair Removal Machine for Beauty Salon
1.Non-chanel laser generator
2.No risk for dirty water caused laser bar burned
3.Biggest energy transfer
4.Light handle, only 852g
Technical Parameters of Fiber Laser Hair Removal Machine for Beauty Salon
Laser Type | Fiber Diode Laser |
Laser wavelength | 808nm |
Energy density | 2J-100J/cm2 |
Pulse width | 5-350 ms adjustable |
Spot size | 10mm*10mm |
